71M651x Software User’s Guide
0x07
0x08 1
5 PULSEW_SRC
PULSER_SRC
PULSEW source and PULSER source. _I refers to imported by the
consumer. _E refers to power exported by the consumer. Values are:
0 – reserved
1 - W0SUM
2 - W1SUM
3 - reserved
4 – reserved
5 - VAR0SUM
6 - VAR1SUM
7 - reserved
8 - I0SQSUM
9 - I1SQSUM
10 - reserved
11 – reserved
12 - V0SQSUM
13 – 15 reserved
16 - VA0SUM
17 - VA1SUM
18 - reserved
19 – reserved
20 – W0SUM_I
21 – W1SUM_I
22 – reserved
23 – reserved
24 – VAR0SUM_I
25 – VAR1SUM_I
26 – reserved
27 – reserved
28 – W0SUM_E
29 – W1SUM_E
30 – reserved
31 – reserved
32 – VAR0SUM_E
33 – VAR1SUM_E
34 – reserved
Table 5-4: Pulse Source Parameters (6511)
