71M651x Software User’s Guide

When prompted for the communication device to be used, select USB ADM51. Click Next.

When prompted for the processor to be used, select either 71M6511 or 71M6513. For all firmware purposes, there is
no difference between 6511 and 6511H or between 6513 and 6513H. Click Next.

Click Finish.
