71M651x Software User’s Guide
Interrupt Enable 1 Register (IE1)
MSB
LSB
swdt
ex6
ex5
ex4
ex3
ex2
Table 6-43: The IEN1 Register
Bit
Symbol
Function
IEN1.7
-
IEN1.6
swdt
Not used for interrupt control
IEN1.5
ex6
ex6=0 – disable external interrupt 6
IEN1.4
ex5
ex5=0 – disable external interrupt 5
IEN1.3
ex4
ex4=0 – disable external interrupt 4
IEN1.2
ex3
ex3=0 – disable external interrupt 3
IEN1.1
ex2
ex2=0 – disable external interrupt 2
IEN1.0
-
Table 6-44: The IEN1 Bit Functions
Interrupt Enable 2 Register (ie2)
MSB
LSB
-
-
-
-
-
-
-
es1
Table 6-45: The IEN2 Register
Bit
Symbol
Function
IEN2.0
es1
es1=0 – disable serial channel 1 interrupt
Table 6-46: The IEN2 Bit Functions
