71M651x Software User’s Guide
tx0_now()
!parity_none_0?
2 stop bits
seven_bit_0?
tx0 |= 0x80
SBUF = tx0
tx0 &= 0x7F
A = tx0
parity_none_0?
A = tx0
TB8 = P ^ parity_odd_0
P ^ parity_odd_0?
tx0 |=0x80
Y
Y
N
N
N
END
no parity Y
tx0 = NUL
insert parity
insert parity
Figure 5-11: tx_now()
