6.3.5.4. Interrupt Sources and Vectors

Interrupt Request Flags

Interrupt Vector Address

ie0 – External interrupt 0

0003H

tf0 – Timer 0 interrupt

000BH

ie1 – External interrupt 1

0013H

tf1 – Timer 1 interrupt

001BH

RI0/TI0 – Serial channel 0 interrupt

0023H

ri1/ti1 – Serial channel 1 interrupt

0083H

iex2 – External interrupt 2

004BH

iex3 – External interrupt 3

0053H

iex4 – External interrupt 4

005BH

iex5 – External interrupt 5

0063H

iex6 – External interrupt 6

006BH

Table 6-59: Interrupt Vectors

External Interrupt Edge Detect

The external interrupts 4, 5 and 6 are activated by a positive transition. The external source must hold the request pin
low (high for int2 and int3, if it is programmed to be negative transition-active) for at least one MPU clk period.
Afterwards, it must be held high (low) for at least one MPU clk period to ensure the transition is recognized and the
corresponding interrupt request flag is set.
