71M651x Software User’s Guide
Opcode
Mnemonic
Opcode
Mnemonic
C0 H
PUSH direct
D0 H
POP direct
C1 H
AJMP addr11
D1 H
ACALL addr11
C2 H
CLR bit
D2 H
SETB bit
C3 H
CLR C
D3 H
SETB C
C4 H
SWAP A
D4 H
DA A
C5 H
XCH A,direct
D5 H
DJNZ direct,rel
C6 H
XCH A,@R0
D6 H
XCHD A,@R0
C7 H
XCH A,@R1
D7 H
XCHD A,@R1
C8 H
XCH A,R0
D8 H
DJNZ R0,rel
C9 H
XCH A,R1
D9 H
DJNZ R1,rel
CA H
XCH A,R2
DA H
DJNZ R2,rel
CB H
XCH A,R3
DB H
DJNZ R3,rel
CC H
XCH A,R4
DC H
DJNZ R4,rel
CD H
XCH A,R5
DD H
DJNZ R5,rel
CE H
XCH A,R6
DE H
DJNZ R6,rel
CF H
XCH A,R7
DF H
DJNZ R7,rel
E0 H
MOVX A,@DPTR F0 H
MOVX @DPTR,A
E1 H
AJMP addr11
F1 H
ACALL addr11
E2 H
MOVX A,@R0
F2 H
MOVX @R0,A
E3 H
MOVX A,@R1
F3 H
MOVX @R1,A
E4 H
CLR A
F4 H
CPL A
E5 H
MOV A,direct
F5 H
MOV direct,A
E6 H
MOV A,@R0
F6 H
MOV @R0,A
E7 H
MOV A,@R1
F7 H
MOV @R1,A
E8 H
MOV A,R0
F8 H
MOV R0,A
E9 H
MOV A,R1
F9 H
MOV R1,A
EA H
MOV A,R2
FA H
MOV R2,A
EB H
MOV A,R3
FB H
MOV R3,A
EC H
MOV A,R4
FC H
MOV R4,A
ED H
MOV A,R5
FD H
MOV R5,A
EE H
MOV A,R6
FE H
MOV R6,A
EF H
MOV A,R7
FF H
MOV R7,A
Table 6-15: Instruction Set in Hexadecimal Order (3/3)
