71M651x Software User’s Guide
M METER DISPLAY
CONTROL (LCD)
Description: Allows user to select internal variables to be displayed.
Usage: M [option]. [option]
Options: None Displays “HELLO” message
0 Disables display updates
1 Temperature (C° delta from nominal)
2 Frequency (Hz)
3. [phase] kWh Total Consumption (display wraps around at 999.999)
4. [phase] kWh Total Inverse Consumption (display wraps around at
999.999)
5. [phase] kVARh Total Consumption (display wraps around at 999.999)
6. [phase] kVAh Total Inverse Consumption (display wraps around at
999.999)
7. [phase] VAh Total (display wraps around at 999.999)
8 Operating Time (in hours)
9 Real Time Clock
10 Calendar Date
11 [phase] V/I Phase at phase (degrees)
12. [phase] (6513) V/V Angle between phases (1= A/B, 2 = A/C))
12.1 (6511)
13.1 (6513) Main edge count (accumulated)
12.2 (6511)
13.2 (6513) CE main edge count for the last accumulation interval
13.1 (6511)
14.1 (6513) Absolute count for W pulses. Reset with CPC command. Demo
Code revision 3.05 only.
13.2 (6511)
14.2 (6513) Count for W pulses in time window defined by the CPD
command. Demo Code revision 3.05 only.
14.1 (6511)
15.1 (6513) Absolute count for VAR pulses. Reset with CPC command.
Demo Code revision 3.05 only.
14.2 (6511)
15.2 (6513) Count for W pulses in time window defined by the CPD
command. Demo Code revision 3.05 only.
Example: M3.1 Displays Wh total consumption of phase A.
Displays for total consumption wrap around at 999.999kWh (or kVARh, kVAh) due to the number of
available display digits. Internal registers (counters) of the Demo Code are 64 bits wide and do not wrap
around.
Values for [phase]: 0 = sum, 1 = A, 2 = B, 3 = C (6513), 0 = sum, 1 = A, 2 = B (6511)
