71M651x Software User’s Guide
Baud Rate Generator
Serial 0 modes 1 and 3 only (Fclk = MPU clock rate):
Timer1 baud rate generator (WDCON.7 = 0)
) 1 256 ( 384
2 mod
th
F
baudrate
s
clk
− ⋅
⋅
=
Internal baud rate generator (WDCON.7 = 1)
) 0 2 ( 64
2
10
mod
rel s
F
baudrate
s
clk
− ⋅
⋅
=
s0rel is a 10 bit value formed by concatenating S0RELH and S0RELL as follows:
s0rel = {S0RELH.[1:0], S0RELL.[7:0]}
Serial 1 all modes: (Fclk = MPU clock rate):
Internal baud rate generator only
) 1 2 ( 32 10 rel s
F
baudrate clk
− ⋅
=
s1rel is a 10 bit value formed by concatenating S1RELH and S1RELL as follows:
s1rel = {S1RELH.[1:0], S1RELL.[7:0]}
