71M651x Software User’s Guide

Instructions that Affect Flags

Instruction

Affected Flag

C

OV

AC

Instruction

Affected Flag

C

OV

AC

ADD

X

X

X

CLR C

0

ADDC

X

X

X

CPL C

X

SUBB

X

X

X

ANL C, bit

X

MUL

0

X

ANL C, /bit

X

DIV

0

X

ORL C, bit

X

DA

X

ORL C, /bit

X

RRC

X

MOV C, bit

X

RLC

X

CJNE

X

SETB C

1

Table 6-16: Instructions Affecting Flags

Operations affecting the PSW or bits in the PSW will also affect flag settings
