71M651x Software User’s Guide
5.13.ALPHABETICAL FUNCTION REFERENCE
Function/Routine
Name
Description Input Output File Name
abs_x()
x = abs(x0); Take absolute value of n-
byte 'x0'.
U08x *x, U08x *x0, n none classics.c
add()
*x += y; where 'x' & 'y' are 'n' bytes
wide.
U08x *x, U08x *y, n U08 classics.c
add_1()
*x += y; where 'x' is 'n' bytes wide, 'y' is
single byte.
U08x *x, y, n U08 classics.c
add8_4() (U64) x += (U32) y; U08x *x, U08x *y none classics.c
add8_8 () (U64) x += (U64) y; U08x *x, U08x *y none classics.c
add8_8() adds two unsigned 8-byte numbers U08x *x, U08x *y none ce.c
API_Init()
Initializes most I/O functions that
control the hardware
none none misc.c
Assign_Resource()
assigns the selected DIO to the
selected internal resource enum USER_PIN pin, enum
IRESOURCE resource
none misc.c
background() executes background processing none none demo.c
cal_begin() starts auto-calibration process none Bbool cal.c
cal_restore() Restores calibration from EEPROM none Bbool cal.c
cal_save() saves calibration data to EEPROM none none cal.c
calibrate()
processes measurements during auto-
calibration
none none cal.c
ce_active() returns CE status none Bbool io651x.c
ce_config()
configures the compute engine with
power equation, PRE_SAMPS and
SUM_CYCLES enum PWR_EQUATION
equation, enum PRE_SAMP
samples, U08 sum_cycles
none io651x.c
ce_enable() Enables or disables the CE Bbool enable none io651x.c
ce_init()
copies CE code and data from flash to
CE DRAM and CE PRAM
none Bbool ce651x.c
ce_outputs_rdy() gets a snapshot of the CE status none Bbool ce.c
ce_reset() resets the CE none none io651x.c
ce_totals_rdy() gets a snapshot of the CE totals none Bbool ce.c
ce_update()
performs the calculations for data just
imported from the CE to the MPU
none Bbool ce.c
cli () command Line Interpreter none none cli.c
cmax()
returns maximum of unsigned char 'a'
and 'b'.
U08 a, U08 b U08 library.c
cmd_ce () processes C commands none none cmd_ce.c
cmd_ce_data_access() Processes context for CE DATA none none access.c
cmd_download()
downloads/uploads code/data between
various sources and serial port
none none load.c
cmd_eeprom() processes EEPROM commands none none cmd_misc.c
cmd_error()
assigns generic command mode error
result code
none none cli.c
cmd_lcd() processes "D" commands none none display.c
