6-24 ADS FlowShark Pulse O&M Manual
GND AE1/2
b16
b18
AI 1
FlowShark Pulse
on the Ri (internal resistance) of the external device
I = 4 - 20mA
mA-output
from exteral flow height
measurement
mA-input
A2Y 2 x 2 x 0.8 or similar, length dependant
+
-
Figure 6-34 Connecting an external transmitter for flow depth measurement
When using sensors in an Ex-area, do not run the sensor cables
past the mechanical shield between the termination blocks. Use
only the 3 cable connections on the sensor connection block!
