C H A P T E R 2

Use and Specifications

Please read this instruction manual thoroughly. It contains all the information
necessary to configure and operate the FlowShark Pulse for proper operation. This
manual is written primarily for qualified technical staff that have adequate knowledge
of measurement technology, automation technology, information technology, and
wastewater hydraulics. Reading and following the instructions in this manual before
initial start-up will help ensure success in device configuration. Do not initiate start-
up until installation is verified and complete.

Part

Description

1

Memory Card Slot

2 Display
3 Keypad
4 Cable

Glands

5

Terminal Clamp Housing

6 USB

Interface

7

Pipe Insertion Sensor

8 Air-Ultrasonic

Sensor

9

Combi Sensor (Flow Velocity, Water Ultrasonic, and Pressure Depth)

Figure 2-1 Overview
