System Overview and Operation
4-9
Sensors
Several sensor models support the FlowShark Pulse. Individual models may vary
based on Ex-protection, cable length, and unique construction. The item number
identifying the sensor model is printed on the sensor where the cable enters the sensor
body and on a nameplate at the end of the cable. A transparent tube on the end of the
cable provides protection for the nameplate against weather conditions and abrasion.
Combi
and Pipe
Insertio
n
Sensors
Active ultrasonic combi and pipe insertion sensors for flow
velocity and depth measurement. Connect to the FlowShark
Pulse. These sensors provide spatial allocation of flow velocities
over a maximum of 16 scan layers.
Sensors
1
Without Depth Measurement
K
Combi sensor made of PPO with PEEK sensor face;
ground plate 1.4571
R
Pipe insertion sensor made of PPO with PEEK sensor
face; pipe body 1.4571
2 With
Water-Ultrasonic
K
Combi sensor made of PPO with PEEK sensor face;
ground plate 1.4571
R
Pipe insertion sensor made of PPO with PEEK sensor
face; pipe body 1.4571
3
With Pressure Measurement Cell (pressure
compensation element required)
K
Combi sensor made of PPO with PEEK sensor face;
ground plate 1.4571
4
With Pressure Measurement Cell and Water-Ultrasonic
(pressure compensation element required)
K
Combi sensor made of PPO with PEEK sensor face;
ground plate 1.4571
Approvals
None
E
Ex zone 1
Cable Lengths
10
10 meters (33 ft)
15
15 meters (49 ft)
20
20 meters (66 ft)
30
30 meters (98 ft)
50
50 meters (164 ft)
5000-
PULSE-
SENS-W
99
100 meters (328 ft)
