Parameter Settings
8-53
Data Structure on the Memory Card
Main Directory
FLASH and PARA Subfolders
Figure 8-84 Data structure on memory card
Flash
This folder represents the location in which the backup file is saved (To execute the
backup, select I/0 > Memory Card > Save backup).
The name of the backup file containing the depth, velocity, flow, and temperature
data written from internal memory is always Q_H_V_T.TXT. The DIAG.TXT file
contains all messages, including error messages which might have occurred during
measurement activities. These may include the beginning and end of Internet
communication, modem restart, or CPU restart after system reset or reprogramming.
The respective message is labelled with the date and time:
>: received error/message
<: reason for error/message cleared
Save the DIAG file by selecting I/0 > Memory Card > Save backup.
PARA
This folder includes all the parameter files with a date stamp. These files allow the
user to retrace transmitter settings involving modifications to the measurement
location and parameter settings. The unit saves the latest modification made within a
particular day.
The filename is PA TT MM JJ .TXT, where TT = day, MM = month, and JJ = year.
name of measurement place.TXT
This is the file in which all of the interval readings are stored. It is saved under the
name of the measurement location.
NIVIDENT.TXT
This text (.txt) file contains the name of the measurement location.
