depth measurement via water-ultrasonic (and redundant
pressure measurement), and temperature measurement to
compensate for the effect of temperature on the velocity of
sound (combi sensor only)

Types of

Construction

• Wedge sensor for installation on pipe bottom
• Insertion sensor for installation through pipe wall with nozzle and

cutting ring

Medium

Contacting

Materials

Polyurethane, stainless steel 1.4571, PPO GF30, PA (combi sensor
only

)

Option: Sensor made of PEEK, resistant against chemical
substances, Hastelloy mounting plate, Titanium mounting plate, FEP
coated cable

Depth Measurement – Water-Ultrasonic

Measurement

Range

0 to 6.56 feet (0 to 200 cm), lowest absolutely measurable depth
0.13 feet (4 cm)

Zero Point Drift

Absolutely stable

Measurement

Error

Less than ±0.08 inches (±2 mm)

Depth Measurement – Pressure

Measurement

Range

0 to 11.5 feet (0 to 350 cm)

Zero Point Drift

Maximum 0.75% of final value (32 °F to 122 °F (0 – 50 °C))

Measurement

Error

<0.5% of final value

Depth Measurement – External Sensor

Measurement

Range

Zero Point Drift

Based on device

Measurement

Error

Flow Velocity Measurement

Measurement

Range

-3.28 to 19.7 feet per second (-100 to +600 cm/s)

Number of Scan

Layers

16 (maximum)

Zero point drift

Absolutely stable zero point

Error Limits

(per scan layer)

<1% of measurement value (v >3.28 feet per second (1 m/s))

<0.5 % of measurement value 0.2 inches per second (+5 mm/s) (v
<3.28 feet per second (1 m/s))

Number of

Sensors

1 to 3 per transmitter
