Troubleshooting 11-5
Error Possible Reason Correction
have been set; analog input has been set
and enabled as the setpoint; and relay
outputs have been enabled.
Check the connection clamps for the correct
wiring and polarity. Connection
When several outputs are in use, make sure
the receiving systems/indicators are not
indicating a voltage. Two analog outputs
share a common ground.
Verify that the output has been enabled.
Verify that specific functions have been
assigned to the correct output channels.
Check the output range (0 or 4-20 mA).
Check the output span.
Check the offset.
Configuration
Check the output signal on the I/O menu
Check cables and connections as well as
input and output terminals.
Check the input range (0 or 4-20 mA) for the
system undergoing monitoring.
Check the input span for the system
undergoing monitoring.
Faulty mA Output
Receiving Systems
Check offset for the system undergoing
monitoring.
Verify whether the memory card is
functioning correctly. Check function in the
I/O – MemoryCard – Info menu.
Make sure the memory card is a card
supplied by ADS. Replace card from
another manufacturer with an ADS-supplied
card.
Verify that the system can support the
memory card capacity. Older systems can
read cards up to 32 or 64 MB. Check the
capacity through the CPU version by
pressing the I key.
The system currently cannot support
memory cards with more than 128MB
capacities.
Memory Card
Verify the method used for formatting cards.
Send cards formatted on a PC to ADS.
Memory Card has No
Data or is Missing
Data
Transmitter Verify that the memory card is seated
