4-10 ADS FlowShark Pulse O&M Manual

Sensor Connection

K

Cable end pre-configured for connection
to 1K/1R and 2K/2R FlowShark Pulse
units

L

Cable end pre-configured for connection
to 3K and 4K FlowShark Pulse units
(pressure compensation element
required
)

Pipe Length

0

(applies only to combi sensor)

2

20 centimeters (8 in) – standard

3

30 centimeters (12 in)– minimum
length for stop valve)

4

40 centimeters (16 in)

G 20 centimeters (8 in) with threaded

extension

Fig. 4-10 Type key for combi sensors

Air-
Ultrasonic
Sensor

Air-ultrasonic sensors measure flow depth without contacting the flow.
Connects to the FlowShark Pulse

Approvals

None

E

Ex zone 1

Cable Lengths

10 10 meters (33 ft)

15 15 meters (49 ft)

20 20 meters (66 ft)

30 30 meters (98 ft)

50 50 meters (164 ft)

99 100 meters (328 ft)

Sensor Connection

500-
PULSE-
SENS-AIR-

K

Cable end pre-configured for connection to
Pulse

Fig. 4-11 Type key for air-ultrasonic sensors

OCS (old model range) passive sensors do not support Model
10/20 transmitters.
