Parameter Settings
8-21
Sensor
No.
Water-Ultrasonic +
Air-Ultrasonic
09
Depth measurements performed using combination
of water-ultrasonic from bottom up and air-
ultrasonic sensor connected directly to FlowShark
Pulse.
Requires a 2K or 4K combi sensor and an air-
ultrasonic sensor.
Water-Ultrasonic +
External Sensor
10
Depth measurement performed using combination
of water-ultrasonic measurement from bottom up
and external 2-wire sensor or external measurement
unit and depth input via mA input signal.
Requires 2K or 4K combi sensor and external 4-20
mA sensor.
Pressure + Water-
Ultrasonic sensor +
external sensor
11
One of two FlowShark Pulse maximum
configurations. Three different depth sensors can
determine the depth level. The sensor-integrated
pressure measurement cell operates in combination
with the water-ultrasonic sensor from bottom up
and with an external 2-wire sensor powered by the
FlowShark Pulse or by an external measurement
unit and depth input via mA input signal.
Requires a 4K combi sensor and an external 4-20
mA sensor.
Pressure + Water-
Ultrasonic + Air-
Ultrasonic
12
This is the second FlowShark Pulse maximum
configuration. Unlike the configuration above, the
third depth detection will be performed by an air-
ultrasonic sensor connected directly to the
FlowShark Pulse. Therefore, this sensor replaces
the external transducer. Both other methods – the
sensor-integrated pressure measurement cell and the
water-ultrasonic sensor from bottom up – will be
used in same way mentioned previously.
Requires a 4K combi sensor and an air-ultrasonic
sensor.
