4-8 ADS FlowShark Pulse O&M Manual
Device Versions
The FlowShark Pulse transmitter and the supporting combi, pipe insertion, and air-
ultrasonic sensors are available in different versions. The tables below provide a
brief overview of the various options.
Transmitter
Transmitters vary primarily based on the power supply, Ex-protection, and enclosure
construction. The article number posted on a label on the bottom of the enclosure
identifies the device type. Refer to the following table for device type specifications.
FlowShark
Pulse Flow measurement transmitter in wall mount enclosure (IP65) for open
channels and partially-filled and full pipes. Spatial allocation of flow
velocities by ultrasound. Signal evaluation using cross-correlation.
Depth measurement based on sensor type via air-ultrasonic, water-
ultrasonic, pressure measurement cell, or mA input for external depth
measurement. Membrane keypad; 128- by 128-pixel graphic display.
Compact flash card slot for data storage. Internet access via HTML
protocol and TCP/IP via Intranet.
Model
10 Standard version with 2 relays, 2 mA outputs (galvanically-
isolated), and 1 mA input (galvanically-isolated with 2-wire sensor
supply) for external depth measurement
20 Multi-functional version with 5 relays, 4 mA outputs (galvanically-
isolated), 4 digital inputs, 5 analog inputs (1 galvanically-isolated
with 2-wire sensor supply), integrated 3-point step controller with
flush function, and connection options for up to 3 sensors
Data Transmission (* B, C, and D currently are not available)
A Internet communication via Ethernet or LAN
B Internet communication via internal analog modem*
C Internet communication via internal ISDN modem*
D Internet communication via GPRS and T-D1*
Power Supply
1 100-240 V AC/47-63 Hz
2 24 V DC regulated
Approvals
None
5000-
PULSE
METER-
E Intrinsically-safe sensor supply in Ex zone 1
Fig. 4-9 Type key for FlowShark Pulse transmitters
