OPERATOR’S MANUAL
AI-120 Virtual Terminal
11001-1606B-201310
90 / MAIN OPERATOR SCREEN
DIAGNOSTICS BUTTON
The Diagnostics window contains information relative to the console’s
operation and USB memory devices connected to the console.
MEMORY USAGE
– Main Memory indicates the percentage amount of internal console
memory that has been used.
– USB Memory indicates the percentage amount of memory used on
an inserted USB device.
– File system
Figure 129
Memory Usage Window
CONSOLE DIAGNOSTICS
Console Diagnostics displays internal temperature, battery voltage,
touchscreen status and the operating time of the console during a powered
state.
Figure 130
Console Diagnostics Window
