OPERATOR’S MANUAL
AI-120 Virtual Terminal
11001-1606B-201310
VARIABLE RATE JOB SETUP / 141
SELECT A VARIABLE RATE TASK
A variable rate task can be selected after a successful import.
1. Press the Task Data Menu button to open menu.
2. Press the Select Task Data button to open Select Task window.
3. Select the desired task to load that appear in the Task column. All
tasks imported appear in this task column.
4. Press the Check button to accept selected task.
Figure 204
Selecting a Task
The variable rate map displays on the guidance screen and a job is now
ready to start.
IMPORTANT: If boundaries and exclusions are not displaying, recheck
how the map was created in the farm management
software tool.
Figure 205
Imported Variable Rate Map
