GUIDELINES / 119
GUIDELOCK GUIDANCE BUTTON
The Guidelock Guidance feature, when enabled, generates a curve based
on existing coverage regardless of when that coverage was laid. This
feature is ideal when steering around a contour or field boundary without
creating and saving a curve or steering along coverage that was treated
earlier that a curve was not created and saved. This guideline method is
also referred to as “free form”.
To Enable Guidelock:
1. Apply coverage and start driving in the desired pattern.
2. Once complete, press the Guideline Menu button.
3. Press the Change Guidance Mode button.
4. Press the Guidelock Guidance button.
5. Drive to the area to begin coverage near the initial coverage path. A
red line locks in parallel to the previous coverage pass to complete
field coverage.
Figure 177
Guidelock Guidance
