4.3 Systems
761 Compact IC
87
mouse button and selecting the menu item
Choose color / ... .
Actual values Display of actual values
Flow, mL/min Display of flow rate of the high-pressure pump.
Pressure max, MPa Display of maximum pressure limit for high-
pressure pump.
Pressure min, MPa Display of minimum pressure limit for high-
pressure pump.
Full scale, µ S/cm Display of selected full scale range.
Remote lines Display of current remote line settings.
Valve Injection valve
Switch injection valve to "INJECT" position.
Switch injection valve to "FILL" position
Suppressor Suppressor module
Switch the suppressor module to the next posi-
tion. The time since the last switching of the
suppressor module is displayed in the field be-
side the button.
IC pump High-pressure pump
Start high-pressure pump.
Stop high-pressure pump.
Peristaltic pump Peristaltic pump
Start peristaltic pump.
Stop peristaltic pump.
System startup values The system startup values are sent and applied
to the 761 Compact IC each time the system is
connected, a determination is started, or the
values are sent manually with .
Flow, mL/min Startup value for flow rate of the high-pressure
pump.
Entry range:
0.20
...
2.50 mL/min
Pressure max, MPa Startup value for maximum pressure limit for
high-pressure pump. This limit is controlled
even without connection to the PC.
Entry range: 0.0 ... 25.0 MPa
Pressure min, MPa
Startup value for minimum pressure limit for
high-pressure pump. This limit is controlled
even without connection to the PC.
Entry range: 0.0 ... 25.0 MPa
Full scale, µ S/cm Startup value for full scale range.
Selection: 50 , 250 , 1000 µ S/cm
Remote lines Startup value for remote line settings 1 … 8.
Selection: 0 , 1
