2.4 Formula editor ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
30 ￭￭￭￭￭￭￭￭ tiBase 1.0
Variable
name
(PC-Control)
Variable
name
( tiBase 1.0 )
Description Data type
SNT .STA Indication whether the statistics is
activated (1 = yes, 0 = no. Number
%SC .STC Start counter Number
%SS Sample table status
1 = Sample table on
0 = Sample table off
Number
2.4.3.8 Common variables
Dialog window: Formula Editor ▶ Variables
Common variables are global variables, which are adopted from the corre-
sponding table of the program part Configuration, where the common
variables can be defined, at the start of the determination and assigned to
the determination. The Variables field of the Formula editor lists all Com-
mon Variables which are available for the current method, sorted accord-
ing to name.
Syntax
'CV.Variable name.Variable name'
Examples: 'CV.TestDate', 'CV.TestTime.VAL', 'CV.Average-
Temp.UNI'
You can select the common variables directly in the formula editor under
Variables/Common Variables in order to avoid syntax errors.
Available Common Variables
Variable
name
(PC-Control)
Variable
name
( tiBase 1.0 )
Description Data type
CV01...CV25 [.VAL] Value of common variables (num-
ber). Text, number or date/time
Usage
870 KF Titrino Plus
With this instrument the two common variables, CV01 and CV02, are
defined for blind values.
877 Titrino Plus, 848 Titrino Plus, 862 Titrosampler
With these instruments there can be defined up to five method-independent
common variables, CV01 to CV05. Common variables are e.g useful for the
following applications:
