4.5 Determination overview ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
238 ￭￭￭￭￭￭￭￭ tiBase 1.0
Selection 13 colors | light green
Default value light green
Auxiliary lines
Selection of the color for the auxiliary lines.
Selection 13 colors | blue
Default value blue
4.5.2.6.4.7 Result Result name
Dialog window: Database ▶ Determination ▶ Reprocessing ▶ Modifications ▶ Cal-
culations ▶ [New]/[Properties] ▶ Result 'Result name' - RS##
In the dialog window Result Result name - RS## results and their prop-
erties can be edited.
The dialog window consists of the following two tabs:
4.5.2.6.4.7.1 Definition
Tab: Database ▶ Determinations ▶ Reprocessing ▶ Modifications ▶ Calcula-
tions ▶ [New]/[Properties] ▶ Result 'Result name' - RS## ▶ Definition
Result variable
Variable, which is automically generated by the program during the evalu-
ation or by the results defined by the user.
Result name
Name of the result. This name will be shown in the result view as well as in
the report. The result name can be used in further calculations as variable
RS.Result name.VAL.
Input 50 characters
Default value empty
Formula
Calculation formula which can be generated after pressing in the for-
mula editor.
Formula lines can be deleted according to normal rules ([Delete]), copied
([Ctrl+C]), cut ([Ctrl+x]) and be pasted ([Ctrl+v])
Input 1000 characters
Default value empty
Unit
Unit of the result for the output (text only). The unit can be used in further
calculations as variable 'RS.Result name.UNI'.
