Metrohm tiBase 1.0 Manual - Manual (Page 175)

￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 4 Database
tiBase 1.0 ￭￭￭￭￭￭￭￭ 167
Input 25 characters
Default value auto
Display measuring points
on | off (Default value: on)
If this check box is activated then the individual measuring points will be
shown on the curve.
Note
With curves, for which the distance between to measuring points is
smaller than 5 pixels, the separate measuring points are not displayed
anymore, even if a symbol has been selected. In this case, the graphics
window can eventually be enlarged in order to display the symbols again.
Scaling
Start value
Initial value for scaling the y-axis.
Range -1.0 E12 ... 1.0 E12
Default value 0.0
End value
End value for scaling the y-axis.
Range -1.0 E12 ... 1.0 E12
Default value 1000.0
4.4.2.2.4 Curve overlay - Options
Dialog window: Database ▶ Tools ▶ Templates ▶ Curve overlay templates... ▶ Curve
overlay templates ▶ [Properties] ▶ Properties - Overlay curves - 'Name'
Options for the graphical display of the overlaid curves.
Display grid
on | off (Default value: off)
If this check box is actjvated then a grid will be shown against the back-
ground.
Grid type
Selection of the type of grid line.
Selection Select line type
