4.7 Subwindow Results ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
262 ￭￭￭￭￭￭￭￭ tiBase 1.0
4.7.3 Results - Raw data
Tab: Database ▶ Results ▶ Results
On the tab Raw data the evaluation results of commands with evaluations
are shown.
"Command name"
For each CALC command the raw data is displayed in six columns:
Column 1
Display of the command type.
Column 2
Shows the variable designation for the raw data.
Columns 3-6
Shows the raw data.
The following tables show the raw data depending on the command type.
For each variable the Variable name, Unit and Number of decimal pla-
ces is indicated.
Table 1 Command DET pH
Column 2: Variable Column 3 Column 4 Column 5 Column 6
EP# EP#.VOL , mL , 4 EP#.MEA , pH , 3 EP#.TIM , s , 1 EP#.TEM , °C , 1
FP# FP#.VOL , mL , 4 FP#.MEA , pH , 3 FP#.TIM , s , 1 FP#.TEM , °C , 1
HP# HP#.VOL , mL , 4 HP#.MEA , pH , 3 HP#.TIM , s , 1 HP#.TEM , °C , 1
MI MI.VOL , mL , 4 MI.MEA , pH , 3 MI.TIM , s , 1 MI.TEM , °C , 1
MA MA.VOL , mL , 4 MA.MEA , pH , 3 MA.TIM, s, 1 MA.TEM , °C , 1
BP# BP#.VOL , mL , 4 BP#.MEA , pH , 3 BP#.TIM , s , 1 BP#.TEM, °C, 1
Table 2 Command DET U
Column 2: Variable Column 3 Column 4 Column 5 Column 6
EP# EP#.VOL , mL , 4 EP#.MEA , mV , 1 EP#.TIM , s , 1 EP#.TEM , °C , 1
FP# FP#.VOL , mL , 4 FP#.MEA , mV , 1 FP#.TIM , s , 1 FP#.TEM , °C , 1
HP# HP#.VOL , mL , 4 HP#.MEA , mV , 1 HP#.TIM , s , 1 HP#.TEM , °C , 1
MI MI.VOL , mL , 4 MI.MEA , mV , 1 MI.TIM , s , 1 MI.TEM , °C , 1
MA MA.VOL , mL , 4 MA.MEA , mV , 1 MA.TIM, s, 1 MA.TEM , °C , 1
BP# BP#.VOL , mL , 4 BP#.MEA , mV , 1 BP#.TIM , s , 1 BP#.TEM, °C, 1
