4.4 Templates ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
166 ￭￭￭￭￭￭￭￭ tiBase 1.0
4.4.2.2.2 Curve overlay - x axis
Dialog window: Database ▶ Tools ▶ Templates ▶ Curve overlay templates... ▶ Curve
overlay templates ▶ [Properties] ▶ Properties - Overlay curves - 'Name'
Parameters for the graphical display of the overlaid curves on the x axis.
x axis
Size
Selection of the quantity to be shown on the x axis.
Selection Command-dependent selection
Label
Freely definable axis label for the x axis. With auto the designation from the
field Size will be used.
Input 25 characters
Default value auto
Scaling
Start value
Initial value for scaling the x axis.
Range -1.0 E12 ... 1.0 E12
Default value 0.0
End value
End value for scaling the x axis.
Range -1.0 E12 ... 1.0 E12
Default value 1000.0
4.4.2.2.3 Curve overlay - y axis
Dialog window: Database ▶ Tools ▶ Templates ▶ Curve overlay templates... ▶ Curve
overlay templates ▶ [Properties] ▶ Properties - Overlay curves - 'Name'
Parameters for the graphical display of the overlaid curves on the y axis.
y axis
Size
Selection of the quantiy to be shown on the y axis.
Selection Command-dependent selection
Label
Freely definable axis label for the y axis. With auto the designation from the
field Size will be used.
