4.5 Determination overview ￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭
236 ￭￭￭￭￭￭￭￭ tiBase 1.0
Smoothing
Smoothing
on | off (Default value: on)
Switches smoothing on/off for the curve.
Smoothing factor x axis
Factor for smoothing on the x axis.
Range 0.01 ... 1000
Default value 0.01
Smoothing factor y-axis
Factor for smoothing on the y axis.
Range 0.01 ... 1000
Default value 0.01
4.5.2.6.4.6.4.5 Properties curve evaluation - Options
Tab: Database ▶ Determinations ▶ Reprocess... ▶ Reprocessing ▶ Curve evalua-
tion ▶ [Edit] ▶ Curve evaluation ▶ Properties ▶ Options
On the tab Options the parameters for the graphical display of the curves
can be set.
Command type
Shows the type of command for which the curve properties can be defined.
The curve properties defined for each command type for the reprocessing
window are saved per client.
Autoscaling
on | off (Default value: on)
If this option is switched on then all axes in the curve window will be scaled
automatically. In this case the fields Start value and End value cannot be
edited.
Display grid
Display grid
on | off (Default value: off)
If this check box is actjvated then a grid will be shown against the back-
ground.
Grid type
Selection of the type of grid line.
