￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭￭ 4 Database
tiBase 1.0 ￭￭￭￭￭￭￭￭ 231
4.5.2.6.4.6.4 Curve evaluation - Properties
4.5.2.6.4.6.4.1 Properties curve evaluation - Overview
Dialog window: Database ▶ Determinations ▶ Reprocess... ▶ Reprocessing ▶ Curve
evaluation ▶ [Edit] ▶ Curve evaluation ▶ Icon 'Properties and Graphical dis-
play' ▶ Properties - 'Curve #'
The properties of the curve display in the dialog window Properties -
'Curve #' can be set on the following 4 tabs:
￭ x axis
Parameters for the graphical display of the curves on the x axis.
￭ y axis
Parameters for the graphical display of the curves on the left y axis.
￭ y2 axis
Parameters for the graphical display of the curves on the right y axis.
￭ Options
Options for graphical display of curves.
4.5.2.6.4.6.4.2 Properties curve evaluation - x axis
Tab: Database ▶ Determinations ▶ Reprocess... ▶ Reprocessing ▶ Curve evalua-
tion ▶ [Edit] ▶ Curve evaluation ▶ Properties ▶ x axis
On the tab x axis the parameters for the graphical display of the curves on
the x axis can be set.
Command type
Shows the type of command for which the curve properties can be defined.
The curve properties defined for each command type for the reprocessing
window are saved per client.
Autoscaling
on | off (Default value: on)
If this option is switched on then all axes in the curve window will be scaled
automatically. In this case the fields Start value and End value cannot be
edited.
Size
Selection Command-dependent selection
Command-dependent selection
Selection of the quantity to be shown on the x axis.
Label
Freely definable axis label for the x axis.
Selection 50 characters | auto
Default value auto
