undone with a double-click on the section of the graph or with the context-
sensitive menu command Show All.
Note
When a new determination is selected the complete curve is always
shown, i.e. the zoom range is not retained when the determination is
changed.
Curves can be copied into the clipboard with the context-sensitive menu
command Copy graphics.
4.8.2 Curves - Measuring point list
Dialog window: Database ▶ Curves
With the context-sensitive menu item Measuring point list... in the curve
window the dialog window Measuring point list - 'Command
name.#' opens for showing the measuring point list for the selected curve.
The display of the measuring points in the table can be defined per window
and per command type in the Properties - Curve #
4.8.3 Properties
4.8.3.1 Curve properties - Overview
Dialog window: Database ▶ Curves ▶ Properties curves #
The properties for the display of curves can be set on the following 5 tabs:
￭ x axis
Parameters for the graphical display of the curves on the x axis.
￭ y1 axis
Parameters for the graphical display of the curves on the y1 axis (left-
hand y axis).
￭ y2 axis
Parameters for the graphical display of the curves on the y2 axis (right-
hand y axis).
￭ Options
Options for graphical display of curves.
￭ Measuring point list
Parameters for showing the measuring point list.
4.8.3.2 Curve properties - x axis
Dialog window: Database ▶ Curves ▶ Properties curves # ▶ x axis
Parameters for the graphical display of the curves on the x axis.
