7 • Use HMI tags
7-3
•
•
•
• •
This rounding method is also used for Numeric Input Enable buttons that use the implicit
decimal position, if an integer tag is assigned to the button’s Value connection. For more
information about the Numeric Input Enable button, see page 21-30.
Use the Tags editor
The Tags editor has these parts: form area, query box, folder hierarchy, and spreadsheet
area.
The information you enter in the form area is shown in the spreadsheet area. The folder
hierarchy shows all the folders that you and FactoryTalk View create.
The Tags editor has special items on the View menu to control the appearance of the
editor, and extra tools on the toolbar.
Use the Tags editor to:
 Create folders
 Duplicate, nest, and delete folders
Form area
Query box
Folder
hierarchy
