20 • Use graphic objects
20-37
•
•
•
• •
 Select the object and then assign tags in the Connections tab of the Property Panel.
 Select the object, and then on the Edit menu click Connections. Assign tags in the
Connections tab of the Properties dialog box.
 Right-click the object, and then click Connections. Assign tags in the Connections tab
of the Properties dialog box.
For information about:
 Use the Tag Browser, see page 6-6.
 Use the Properties dialog box, see page 20-27.
 Use the Property Panel, see page 20-30.
Use expressions to manipulate tag values
Many of the connections to which you can assign a tag also permit the use of expressions
to perform logical or mathematical calculations on tag values. If you assign an expression,
Type the tag
name here...
...or click the button
to open the Tag
Browser.
