B • Convert PanelBuilder and PanelBuilder32 applications
B-11
•
•
•
• •
Maintained push Button, Multistate
Push Button, Standard Control List
Selector Initial state values If you want to set these objects’ states on
application startup, create a macro to set
the appropriate tag values for the objects’
connections. For information about
macros, see Chapter 30. Assign the
macro in the Startup editor. For details,
see Help.
Multistate Indicator, Message Display Print Setting
Bar Graph Inner text and inner graphic Converted to a separate text object and
image object.
Gauge Inner text and inner graphic
Scale clipping
Needle
Converted to a separate text object and
image object.
If the scale doesn’t fit within the height or
width of the gauge, it is not clipped.
Check the position of the scale to ensure
it doesn’t overlap other objects.
Converted to a separate gauge object; if
the gauge had 2 needles, each needle is
converted to a separate gauge object.
Alarm List No Acknowledgement Required All alarms can be acknowledged.
All objects Image placement FactoryTalk View supports one, three or
nine positions for images, depending on
the type of object. On conversion, images
are positioned using the closest match.
Therefore some images might be clipped
to fit the object.
All objects Turn Object View On property If this property is set to False, the
converted object has a transparent
background, no border, no caption, and
no image.
All objects Blinking inner graphics If the inner graphic uses a color image, it
will not blink. Use a monochrome image
if you want the inner graphic to blink.
Graphic object
Unsupported feature in FactoryTalk
View
Notes
