F ACTORY T ALK V IEW M ACHINE E DITION U SER ’ S G UIDE
20-10
• •
•
•
•
Show alarms and messages
RecipePlus button Display data set and tag values for ingredients in the RecipePlus table. Write
tag values from the selected data set to the data source. Write tag values from
the data source to the selected data set or to a new data set. Save data set
values from the table to a recipe file. Rename or delete recipe units. For
details, see page 29-3.
RecipePlus selector Select the recipe unit to show, download from, write to, rename, or delete.
For details, see page 29-2.
RecipePlus table Display and compare recipe data set values and tag values. Edit data set
values. For details, see page 29-2.
ActiveX object Enter or show data using a third-party object connected to an analog, digital,
or string tag, including both HMI and data server tags. The format of the data
entered or shown depends on the object. For details, see page 20-22.
Use this graphic object To show this
Alarm list Multiple alarm messages, including the time the alarms are triggered and
acknowledged. For details, see page 9-32.
Alarm banner A single unacknowledged alarm message. For details, see page 9-34.
Alarm status list The status of alarms, including how many times an alarm has been triggered
and how long it has been active. For details, see page 9-34.
Diagnostics list Messages about system activity such as tag reads, tag writes, and
communications errors. For details, see page 10-12.
Information message display Messages about the process, prompts or instructions, and information about
current states. For details, see page 27-6.
Local message display Ongoing information about the status of devices or processes. For details,
see page 19-30.
Use this graphic object To do this
