F ACTORY T ALK V IEW M ACHINE E DITION U SER ’ S G UIDE
4-12
• •
•
•
•
resolution of the screen in pixels. For information on setting the project window size, see
page 4-17.
Screen resolution for PanelView Plus 7, PanelView Plus 6,
PanelView Plus, and PanelView Plus CE terminals
If you are going to run your application on a PanelView Plus 7, PanelView Plus 6,
PanelView Plus, or PanelView Plus CE terminal, select one of these project window sizes:
For this terminal or monitor Select this project window size
PanelView Plus - 400 or 600
PanelView Plus Compact - 400 or 600
PanelView Plus 6 - 400 or 600
PanelView Plus Compact 6 - 400 or 600
320x240
PanelView Plus 7 4” Wide 480x272
PanelView Plus - 700 or 1000
PanelView Plus CE - 700H or 1000H
PanelView Plus 6 -700 or 1000
PanelView Plus Compact - 1000
PanelView Plus 7 6” or 7”
640x480
PanelView Plus 7 9” Wide 800x480
PanelView Plus - 1250
PanelView Plus CE - 1250H
PanelView Plus CE - 1200P, 1200M, or 1200W
PanelView Plus 6 - 1250
PanelView Plus 7 10”
800x600
PanelView Plus - 1500
PanelView Plus CE - 1500H
PanelView Plus CE - 1500P, 1500M, or 1500W
PanelView Plus 6 - 1500
PanelView Plus 7 15”
1024x768
PanelView Plus 7 12” Wide 1280x800
PanelView Plus CE - 1700M
PanelView Plus 7 19”
1280x1024
