F ACTORY T ALK V IEW M ACHINE E DITION U SER ’ S G UIDE
20-18
• •
•
•
•
7. To close the dialog box, click OK.
You can also use the Arc and Wedge tools to reshape arcs and wedges. For more
information, see page 20-47.
Create ellipses and circles
Use the Ellipse tool to draw an ellipse or circle.
To create an ellipse or circle
1. Select the Ellipse tool.
2. Click the mouse where you want to position the object, and then drag to draw an
ellipse or circle of the desired size.
To draw a circle, hold down Ctrl while you drag.
3. To change how the object looks, double-click it to open the object’s Properties dialog
box.
4. Select circle or ellipse options.
For information about the options in the dialog box, see Help.
5. To close the dialog box, click OK.
Create freehand shapes
Using the Freehand tool is similar to drawing with a pen on paper.
To create a freehand shape
1. Select the Freehand tool.
2. Click and drag to create the shape you want.
3. To change how the object looks, double-click it to open the Freehand Properties dialog
box.
4. Select freehand options.
For information about the options in the dialog box, see Help.
5. To close the dialog box, click OK.
Create lines
To create a line
1. Select the Line tool.
Ellipse tool
Freehand tool
