Publication 1746-6.1.2 - July 2000
Installing Your SLC Servo Module 4-3
To insert a module into an I/O chassis:
1. Remove backplane power from the I/O chassis.
2. Remove user-side power from the SLC Servo Module.
3. Disconnect the 1746-HCA cable.
4. Align the larger of the two boards of the SLC Servo Module with
the card-edge guide at the bottom of the chassis.
5. Slide the module into the chassis.
6. Press the module firmly to seat it into the backplane connector.
7. Verify that the locking latches on the top and bottom of the
chassis hold the module in place.
An invalid configuration is
detected CONFIG INV
ATTENTION
!
To avoid personal injury, equipment damage, or
performance degradation, remove backplane power
from the chassis and disconnect the 1746-HCA cable
before installing or removing a module.
ATTENTION
!
To avoid damage to a module or backplane
connector, do not force modules into the backplane
connector.
IMPORTANT
The term user-side refers to the control circuitry on
the SLC Servo Module card that is powered by
customer-supplied power sources and isolated from
the control circuitry that is powered by the
backplane of an SLC rack.
When: This LED is on:
