4 Rockwell Automation Publication 1715-UM001C-EN-P - March 2014
Summary of Changes
Added information about analog field loops, input modules and analog input field
devices
98
Find and record MAC addresses 109
Added status indicator labels to the adapter graphic of the locking mechanism 110
Changes throughout the Assign an IP Address on the BOOTP/DHCP Server section 111
Verify BOOTP network settings Important table added 112
Added last step to disable BootP/DHCP 114
Module inhibiting when using multiple controllers 128
Corrected ohms symbol and added DC on voltage numbers 132
Shutdown states 137
Removed references to the 1756-IA16 module 138
Digital input module tags 138
Digital output module tags 139
Correction of table header to ControlLogix Analog I/O Modules and Components 142
Added performance criteria for the analog input module 143
Added performance criteria for the analog output module 144
Module inhibiting when using multiple controllers 145
Changed Get Support Now website to the Product and Compatibility Download Center
website, added Add-On Profile versions for the adapter and I/O modules. Added
reference to the release list of approved versions on www.tuvasi.com.
150
Updated screen shots throughout to reflect Logix Designer version 21 interface and to
include SIL 2 operation options
160
Connections for Listen Only 162
Module definition parameters for 1715-IB16D digital input module in Duplex mode for
SIL 2 applications
175
Connections for Listen Only 188
Added Important table about changing Alarms/Limits values 196
Added a new chapter about SIL 2 safety operation with 1715 redundant I/O 201
Added a new chapter about SIL 2 Add-On Instructions with 1715 redundant I/O 223
Corrected text from 3.9 to 4.3. 282
Corrected text from 15 to 15.4. Added Calibration Drift Checks section. 283
SIL 2 safety application online configuration restrictions 285
Added appendix for PFD and PFH calculations for a SIL 2 system 289
Added appendix for SIL 2 Applications Checklist 303
Added appendix for Tag Definitions 305
Table 1 - New and Updated Information
Topic Page
