Appendix G
I/O Tag Definitions
PortA1ANSTatus
SINT, enumerated
Enumerated adapter module Ethernet port auto-negotiation status:
Value
Description
0
Auto-negotiation in progress
1
Auto-negotiation of duplex and speed detection failed; by using a default value for
speed and duplex
2
Auto-negotiation of duplex but detected speed; by using a default value for duplex
3
Successfully negotiated duplex and speed
4
Auto-negotiation not attempted, by using forced speed and duplex values
5-255
Undefined
PortA2ANStatus
SINT, enumerated
Enumerated adapter module Ethernet port auto-negotiation status:
Value
Description
0
Auto-negotiation in progress
1
Auto-negotiation of duplex and speed detection failed; by using a default value for
speed and duplex
2
Auto-negotiation of duplex but detected speed; by using a default value for duplex
3
Successfully negotiated duplex and speed
4
Auto-negotiation not attempted, by using forced speed and duplex values
5-255
Undefined
PortB1ANStatus
SINT, enumerated
Enumerated adapter module Ethernet port auto-negotiation status:
Value
Description
0
Auto-negotiation in progress
1
Auto-negotiation of duplex and speed detection failed; by using a default value for
speed and duplex
2
Auto-negotiation of duplex but detected speed; by using a default value for duplex
3
Successfully negotiated duplex and speed
4
Auto-negotiation not attempted, by using forced speed and duplex values
5-255
Undefined
PortB2ANStatus
SINT, enumerated
Enumerated adapter module Ethernet port auto-negotiation status:
Value
Description
0
Auto-negotiation in progress
1
Auto-negotiation of duplex and speed detection failed; by using a default value for
speed and duplex
2
Auto-negotiation of duplex but detected speed; by using a default value for duplex
3
Successfully negotiated duplex and speed
4
Auto-negotiation not attempted, by using forced speed and duplex values
5-255
Undefined
PortA1Speed
DINT
Interface speed in Mbps that is currently in use, for example, 10 Mbps or 100 Mbps, or 0 when port is active
PortA2Speed
DINT
Interface speed in Mbps that is currently in use, for example, 10 Mbps or 100 Mbps, or 0 when port is active
PortB1Speed
DINT
Interface speed in Mbps that is currently in use, for example, 10 Mbps or 100 Mbps, or 0 when port is active
PortB2Speed
DINT
Interface speed in Mbps that is currently in use, for example, 10 Mbps or 100 Mbps, or 0 when port is active
CIPTimeouts
DINT
Total of all Connection Manager object Connection Timeout values
Table 76 - Input
Tag Name
Data Type
Definition
