Rockwell Automation Publication 1715-UM001C-EN-P - March 2014
3
Summary of Changes
This publication contains new and updated information. Changes throughout
this revision are marked by change bars, as shown to the right of this paragraph.
New and Updated
Information
This table contains the changes made to this publication revision.
Table 1 - New and Updated Information
Topic
Page
Updates to include SIL 2 operations with L7 ControlLogix® controllers
Studio 5000® Logix Designer™ application added throughout document and new
information about who can use this system
Using ControlLogix in SIL 2 Applications Safety Reference Manual added to Additional
Resources section
Added redundant 1715 adapter module and status indicator information
Added information about using a 1715 system in a SIL 2 application
Corrected drawing; added 1756-L7 controller and 1756-RM2 module; added reference
for DLR topologies.
Corrected drawing; added 1756-L7 controller and 1756-RM2 module
Network status indicator information
CIP messages
Required connections for duplex and simplex operation
Listen Only connections
Conformal coating is available on all 1715 modules
1715-A2A adapter base unit fuse graphic and removal and replacement information
Digital input termination assembly removal and replacement of fuses
Digital output termination assembly removal and replacement of fuses
Analog input termination assembly removal and replacement of fuses
Power requirements
1715 chassis firmware upgrade; power recycle needed
ControlFLASH™ revision number
Power requirements for PELV/SELV
Correction to system power graphic
Digital Input diagram correction-standard inputs
Short circuit information
Digital Input diagram correction-line monitored inputs. Added reference for calibration
drift checks.
Corrected digital input termination assembly graphics
Added Attention table for inductive loads
Added missing arrow on 1715-OB8DE function block diagram, going from the Control B
box to the Output Control.
Diagram correction-digital outputs
Damaging pins when inserting/removing I/O modules under power can fault the system
Corrected analog inputs graphic by removing footnote numbers on voltage
