Specifications 5-5

Publication 198-UM001B-EN-P September 2001

Table 5.C 198-DN and 198-DNG General Specifications

Terminal Block (5.08 mm Pitch 5-Position)

Connection Capacity

Solid wire

0.13…1.5 mm

2

(24…16 AWG)

Flexible wires

0.13…2.5 mm

2

(24…14 AWG)

Flexible wires with ferrules

0.5…2.5 mm

2

(20…14 AWG)

Plastic collar

1.5 mm

2

(16 AWG)

Wire Type

Use 75 C copper wire min.

Tightening Torque

0.5…0.6 Nm (4.4…5.3 lb-in.)

Connector (M12 Male 5-Pin)

M12 Mounting Hole

16 mm (5/8 in.)

M12 Thread

M12 x 1 mm

M12 Connector Torque

1.4 Nm (12 lb-in.)

Electrical

DeviceNet Supply Voltage

11.0…25.0V DC

DeviceNet Input Current (no options)

55 mA max.

DeviceNet Input Current Max.

1.8 A

DeviceNet Input Current Surge

15 A for 250

µS

Environmental

Ambient Temperature

Operating

–25…+60

°C (–4…+140°F)

Storage

–40…+85

°C (–40…+185°F)

Relative Humidity

0…95% (non-condensing)

Shock

Operating

30 g peak acceleration

Non-Operating

50 g peak acceleration

Operating Vibration

10 g @ 58…2000 Hz
0.030 in. peak-to-peak displacement 2…57 Hz
Per IEC 68-2-6

DeviceNet Communications

Baud Rates

125, 250, 500 kbps

Distance Max.

500 m (1630 ft) @ 125 kbps
200 m (656 ft) @ 250 kbps
100 m (328 ft) @ 500 kbps

Approvals

Agency Certification

cUL
UL Listed
CE Marked for all applicable directives
