Mod/net status led, Mod/net status led -31 – Rockwell Automation 198x Modular DeviceNet Starter Auxiliary I/O User Manual
Page 51

3-31
Publication 198-UM001B-EN-P September 2001
Refer to Appendix A for a more detailed description of each attribute shown in the tables
above.
Mod/Net Status LED
The Module/Network Status LED is a bi-colored (red/green) LED that provides status
information on DeviceNet communications. Table 3.K summarizes the operation of the
LED.
Table 3.J I/O Input Assembly Data Attribute Mapping
Data Component Name
Class
Instance
Number
Attribute
Name
Number
Name
Number
I/O Status Word
DeviceNet Interface
OB4hex
1
I/O Module
Status
22
Error Code
DeviceNet Interface
OB4hex
1
Error Code
25
Module Error Number
DeviceNet Interface
OB4hex
1
Module Error
Number
29
Module 2 Input 1
DIP
O8hex
1
Value
3
Module 2 Input 2
DIP
O8hex
2
Value
3
Module 2 Input 3
DIP
O8hex
3
Value
3
Module 2 Input 4
DIP
O8hex
4
Value
3
Module 3 Input 1
DIP
O8hex
5
Value
3
Module 3 Input 2
DIP
O8hex
6
Value
3
Module 4 Input 1
DIP
O8hex
7
Value
3
Module 4 Input 2
DIP
O8hex
8
Value
3
Module 5 Input 1
DIP
O8hex
9
Value
3
Module 5 Input 2
DIP
O8hex
10
Value
3
Module 6 Input 1
DIP
OEhex
1
Value
1
Module 6 Input 2
DIP
OEhex
2
Value
1
Module 4 Open
DIP
OEhex
1
Value
122
Module 5 Short
DIP
OEhex
1
Value
123
