2-3 Installation

Publication 198-UM001B-EN-P September 2001

Approximate Dimensions

Dimensions are in millimeters (inches).

Figure 2.1 DIN Module Mounting Dimensions

IMPORTANT

Maintain spacing from enclosure walls, wireways, adjacent equipment,
etc. Allow 25 mm (1 in.) of space on all sides for adequate ventilation,
as shown:

85

(3-11/32)

77

(3-1/16)

18

(11/16)

98

(3-27/32)

78

(3-1/16)

78

(3-3/32)

76

(2-31/32)

Vent Side

Connector Side

End

End

Dev

ic

eNet

Mo

d-

DS

A I/

O

Mo

d-

DS

A I/

O

Mo

d-

DS

A I/

O

Mo

d-

DS

A I/

O

Connector
Side

End

25mm (1 in)

25mm
(1 in)

Vent
Side

End

25mm (1 in)

25mm
(1 in)
