window. This procedure can be repeated for all of the input points for both of the Off to
On delay and On to Off delay.

EXAMPLE

The following example will set the Idle Action of output 1 of the DC Starter to Hold Last
State. See the lineup established in Figure 3.1.
The same steps as the above example will be taken to obtain the values of the Class,
Instance, and Attributes for the following:

In the above screen, “Data sent” should be “1”. The “values in decimal” option should be
checked.
Make the desired changes. In this example, to set the Idle Action of Output 1 of the Dc
Starter to Hold Last State, click the

([HFXWH button. This procedure can be repeated for

all of the output points for Fault Action, Fault Value, Idle Action, and Idle Value.

IMPORTANT

The MDSA cannot be mapped to the scanlist while using the Class
Instance editor. There will be a communication error displayed if you
execute an instruction.
