Specifications 5-45

Publication 198-UM001B-EN-P September 2001

Figure 5.33 Replacing Cat. No. 198-IB2XOB1 Series A Module with

Series B Module

ATTENTION

!

Make sure all power has been removed from the modules and all other
components inside the enclosure.

Replacing Series A Module with Series B Module
