A-22 DeviceNet Information
Publication 198-UM001B-EN-P September 2001
➊ 0 = Empty
1 = Sensor Module
2 = AC Starter Module
3 = DC Input Relay Output
4 = 2 AC Input Module
5 = 4 DC Input Module
6 = Reserved
7 = 2 Output Module
8 = DC Starter
9 = Future
45 Get Module ID Slot 12 USINT ➊
46 Get Module ID Slot 13 USINT ➊
47 Get Module ID Slot 14 USINT ➊
48 Get Module ID Slot 15 USINT ➊
49 Get Module ID Slot 16 USINT ➊
Table A.34 DeviceNet Interface Object Common Services
Service Code Implemented for: Service Name
Class Instance
0x0E Yes Yes Get_Attribute_Single
0x10 No Yes Set_Attribute_Single
Table A.33 DeviceNet Interface Object Instance Attributes (Continued)
Attribute
ID
Access
Rule
Name Data Type Value
