Devicenet object— class id (03hex), Devicenet object — class id (03hex) – Rockwell Automation 198x Modular DeviceNet Starter Auxiliary I/O User Manual
Page 146

A-6 DeviceNet Information
Publication 198-UM001B-EN-P September 2001
DeviceNet Object — Class ID (03hex)
The following class attributes are supported for the DeviceNet Object:
The following instance attributes are supported:
➊
Allocation byte:
Bit 0
Explicit Messaging
Bit 1
Polled I/O
Bit 4
Change of State (COS) I/O
Bit 5
Cyclic I/O
Bit 6
Acknowledge Suppress I/O
Table A.5 DeviceNet Object Class Attributes
Attribute ID
Access Rule
Name
Data Type
Value
1
Get
Revision
UINT
1
Table A.6 DeviceNet Object Instance Attributes
Attribute
ID
Access
Rule
Name
Data Type
Value
1
Get/Set
MAC ID
USINT
0…63
2
Get/Set
Baud Rate
USINT
0 = 125 K baud
1 = 250 K baud
2 = 500 K baud
3
Get/Set
BOI
BOOL
0 = Hold in error state on detection of BOI
1 = Reset CAN chip on detection of BOI
4
Get/Set
Bus-off Counter
USINT
Range 0…255
5
Get
Allocation Information
Allocation Choice Byte
Master’s MAC ID
Structure:
BYTE
USINT
Allocation byte
➊
0…63 = Address
255 = Unallocated
6
Get
MAC ID
Switch Changed
BOOL
0 = No change
1 = Change since last reset or power-up
8
Get
MAC ID
Switch Value
USINT
Actual value of node address switches
Range 0…99
Address 64…99
Software settable
100
Get/Set
AutoBaud Disable
BOOL
0 = Enable (default)
1 = Disable
