Product Overview 1-4

Publication 198-UM001B-EN-P September 2001

Cat. Nos.

The catalog numbering scheme for the Modular-DSA I/O System is explained in Figure 1.4
and Figure 1.5 belo
w. Note that all cat. nos. begin with 198, which stands for Bulletin 198
Modular-DSA I/O System.

Figure 1.4 Modular DSA — DeviceNet Cat. No.

Figure 1.5 Modular-DSA I/O System — I/O Module Cat. No.

DeviceNet Compatibility

The Modular-DSA I/O System communicates as a Group 2 slave device via DeviceNet
Protocol. It supports the Explicit, Polled I/O, and Change of State (COS) I/O messaging of
the predefined master/slave connection set and two additional explicit connections available
through Group 1 or Group 3.

G

Gland Plate

No Selection

DIN Mount

DN

DeviceNet

Bulletin No.

198 – DNG

No. of Inputs

No. of Outputs

Output

AND

Input

Bulletin No.

Input Type

A

AC

B

DC

Output Type

W

Relay

B

DC

DeviceNet Sourced

Q5

M12 1-Key 5-Pin

G4

1/2" 2-Key 4-Pin

198 – IB2XOB2S-Q5
