5-68 Specifications

Publication 198-UM001B-EN-P September 2001

Table 5.AI Gland Plate Specifications

Environmental

Ambient Temperature

Operating

–25…+60

°C (–4…+140°F)

Storage

–40…+85

°C (–40…+185°F)

Relative Humidity

0…95% non-condensing

Shock

Operating

30 g peak acceleration

Non-Operating

50 g peak acceleration

Operating Vibration

10 g @ 58…2000 Hz
0.060 in. peak-to-peak displacement 2…57 Hz
Per IEC 68-2-6

Mounting Screws

Thread Forming
Torque

1.3…2.0 Nm (11.5…17.7 lb-in.)
(For enclosure wall thickness of 2 mm (0.079 in.) and
4.57 mm (0.180 in.) hole diameter)

Assembly
Torque

2.8 Nm (25 lb-in.)

Ratings

NEMA 3/4/12, IP66

Approvals

Agency
Certification

UL/cUL Recognized
